Notes on M.A.C.H.3

The "Original" LaserCon LDP conversion card can be used to upgrade M.A.C.H.3 to a modern laserdisc player.
The LDP converter can replace the PR-8210 or the LD-1100, whether it is controled via IR remote-control or direct wire.

The only replacement Laserdisc player for M.A.C.H.3 is the Pioneer LD-V8000.

Your LD-V8000 must be run at 4800 baud rate.
LaserCon Firmware 7.0 or higher is required.
Set LaserCon switches 1-4: ON OFF OFF OFF

Version 1.X of the LaserCon LDP Conversion board was not configured to work with games using the the PR-8210/A or LD-1100 Laserdisc players.
If you have one of these earlier boards, you must modify it for use with the PR-8210.


Download and follow these instructions first --> Direct-wire 8210 Modification for MACH3

-

MACH3 Set-up Instructions for The LDP Converter
