Notes on Astron Belt

Only the Pioneer LD-V1000 version of Astron Belt works with LaserCon, The VIP-9500 version is NOT supported.
Astron Belt and Galaxy Ranger are the same hardware.

The "Original" LDP Conversion board can be used to upgrade Astron Belt to a modern laserdisc player.

The replacement Laserdisc players are the a Pioneer LD-V8000, LD-4400, LD-4300D
Set your player to 9600 baud rate
Set LaserCon switches 1-4: OFF ON OFF ON


AB Set-up Instructions for LD-V1000 Games
